User’s Manual of IGS-4215-16T2S
4.13.10.3 IPv4-based ACL
This page shows the ACL status by different ACL users. Each row describes the ACE that is defined. It is a conflict if a specific
ACE is not applied to the hardware due to hardware limitations. IPv4-based ACL screens in Figure 4-13-70 and Figure
4-13-71appear.
Figure 4-13-70: IPv4-Based ACL Page Screenshot
The page includes the following fields:
Object Description
• ACL Name
Create a named IPv4-based ACL list.
Buttons
: Click to add ACL name list.
Figure 4-13-71: ACL Table Page Screenshot
The page includes the following fields:
Object Description
• Delete
Click to delete ACL name entry.
