User’s Manual of WGS Managed Series
320
Figure 4-12-13 Port LLDP MED Configuration Page Screenshot
The page includes the following fields:
Object Description
• Interface
The switch port number of the logical port
• LLDP MED Status
Display the current LLDP MED status
• Active
Display the current active status
• Application
Display the current application
• Location
Display the current location
• Inventory
Display the current inventory
The MED Location Configuration and LLDP MED Port Location Table screens in Figure 4-12-14 & Figure 4-12-15 appear.
Figure 4-12-14 Port LLDP MED Configuration Page Screenshot
