User’s Manual of WGS Managed Series
The page includes the following fields:
Object Description
• Port
Select port from this drop-down list
• Location Coordinate
A string identifying the Location Coordinate that this entry should belong to
• Location Civic
Address
A string identifying the Location Civic Address that this entry should belong to
• Location ESC ELIN
A string identifying the Location ESC ELIN that this entry should belong to
Buttons
: Click to apply changes.
Figure 4-12-15 LLDP MED Port Location Table Page Screenshot
The page includes the following fields:
Object Description
• Port
The switch port number of the logical port
• Coordinate
Display the current coordinate
• Civic Address
Display the current civic address
• ESC ELIN
Display the current ESC ELIN
