User’s Manual of WGS Managed Series
SFP 17 and SFP 18
LED Color Function
1000
LNK/ACT
Green
Lights:
To indicate the link through that port is successfully established at 1000Mbps.
Blinks: To indicate that the switch is actively sending or receiving data over that port.
100
LNK/ACT
Amber
Lights: To indicate the link through that port is successfully established at 100Mbps.
Blinks: To indicate that the switch is actively sending or receiving data over that port.
■ PoE Power Usage (Unit: Watt)
LED Color Function
60W Amber
Blinks
To indicate the system consumes between 30 watts and 60 watts of PoE power
Lights
To indicate the system consumes between 60 watts and 90 watts of PoE power
120W Amber
Blinks
To indicate the system consumes between 90 watts and 120 watts of PoE power
Lights
To indicate the system consumes between 120 watts and 150 watts of PoE power
180W Amber
Blinks
To indicate the system consumes between 150 watts and 180 watts of PoE power
Lights
To indicate the system consumes between 180 watts and 210 watts of PoE power
240W Amber
Blinks
To indicate the system consumes between 210 watts and 240 watts of PoE power
Lights
To indicate the system consumes over 240 watts of PoE power
