If you want to modify the presets presented in section "Presets" on page
140, you can do so by following the steps below.
Steps
1. Activate the micromotor.
2. Press Torque.
3. Select the micromotor’s drive mode.
Toggle between the drive modes by pressing the current drive mode -
button.
The modes are:
Auto stop
The micromotor stops when the torque limit is
reached.
Auto reverse
When the torque limit is reached the micromotor will
operate counter-clockwise.
Auto forward
When the torque limit is reached, the micromotor will
operate counter-clockwise (auto reverse) for 2
seconds and then return to clockwise direction.
The length of the counter-clockwise rotation is
adjusted in step 13.
4. Press Program.
5. Press RPM limit to adjust the micromotor speed rate.
A pop-up window opens.
6. Adjust the micromotor speed rate (RPM).
Alteration of RPM speed rate in different ranges
Range In steps of:
100 - 200 10 (e.g. 110, 120 etc...)
200 - 500 20 (e.g. 220, 240, 260 etc...)
500 - 1 000 50 (e.g. 550, 600, 650 etc...)
1 000 - 2 000 100 (e.g. 1 100, 1 200 etc...)
2 000 - 5 000 200 (e.g. 2 200, 2 400 etc....)
5 000 - 10 000 500 (e.g. 5 500, 6 000, 6 500 etc...)
10 000 - 20 000 1 000 (e.g. 11 000, 12 000 etc....)
