Micromotor, turbine
Action Function
Pedal left / pedal right Drive instrument
Pedal down, short activation Change spray water & air / air / off
Pedal down, long activation Manual chip blow; activated for as long as the pedal is
pushed and held down
Scaler
Action Function
Pedal left / pedal right Drive instrument
Pedal down, short activation Change spray 1 / 2 / off
Unit controlled polymerisation light
Action Function
Pedal left / pedal right / pedal down Start / stop instrument
Intraoral camera
Action Function
Pedal left / pedal right Freeze / unfreeze picture
Pedal down Save still picture
Intraoral scanner
Action Function
Pedal left Move upward in the list of scan type selection tools
Pedal right Move downward in the list of scan type selection tools
Pedal down, short activation Start scanning
Pedal down, long activation Take image
14.4 Wireless foot control
NOTE
The wireless foot control is an optional feature.
The standard foot control and the wireless foot control can not be used
simultaneously. Should such a situation occur, the standard foot control
overrides the wireless foot control.
When the wireless foot control has been idle for 2 hours, it goes into sleep
mode. You are notified about this with a message on the control panel. The
sleep mode is also indicated by a battery symbol on the control panel. Wake
up the foot control by pressing the foot control handle.
Before using the wireless foot control, check the power level of its battery.
The power level is indicated by a battery symbol on the control panel.
Power level Sleep mode Full < 40% full < 20% full
14 Foot control
78 Planmeca Compact i User's manual
