14.3 Foot control functions
14.3.1 Centre knob functions
NOTE
When the motorised headrest is activated, the centre knob activates other
features than those presented below. For more information, see section
"Operating motorised headrest" on page 107.
Action Function
Centre knob left Chair to automatic position A
Centre knob left, long activation Backrest down
Centre knob right Chair to automatic position B
Centre knob right, long activation Backrest up
Centre knob up Chair to automatic position C
Centre knob up, long activation Chair up
Centre knob down Chair to automatic position D
Centre knob down, long activation Chair down
14.3.2 Left-side and right-side knob functions
Action Function
Left-side knob up Can be configured by a Planmeca service technician.
Default function: Operating light on/off
Left-side knob down Can be configured for a selection of instruments by a
Planmeca service technician.
The function depends on the selected instrument slot.
Only one function per instrument slot can be
configured.
Right-side knob up Can be configured by a Planmeca service technician.
Default function: Intraoral camera on/off
Right-side knob down Chair to rinsing position.
14.3.3 Pedal functions
The factory default functions of the foot control pedal when the dental unit is
equipped with a standard pedal and no instrument is activated are presented
below.
Action Function
Pedal left Assistant call
Pedal down, short activation Cup fill and bowl rinse
Pedal down, long activation Cup fill for as long as the pedal is pressed
Pedal right & down Chair to rinsing position
When an instrument is activated, the functions of the standard pedal depend
on the used instrument. These instrument-specific functions are presented
below.
14 Foot control
User's manual Planmeca Compact i 77
