3. Open the
Intensity
tab.
4. Adjust the intensity of the operating light or the composite mode.
The active foot control icon shows which value can be
adjusted by pushing the foot control pedal to the left or
right. To activate the inactive value, press down the foot
control pedal or press the plus (+) or minus (-) button of
the inactive value.
The minimum value is 30% of the maximum intensity and the maximum
100%, and the adjustment step is 5.
5. Press OK.
The pop-up window closes and the new values are displayed on the
control panel.
25.7.2 Colour temperature and brightness
About this task
NOTE
The colour temperature can also be adjusted from the operating light, see
section "Changing light tone of operating light" on page 122.
Steps
1. Press Program.
25 Programming
User's manual Planmeca Compact i 191
