12.2 Automatic legrest
The automatic legrest can be moved synchronously to the movements of the
backrest, that is, when you drive the backrest down, the automatic legrest is
driven up. Use the chair movement buttons to drive the patient chair. Notice
that the lever underneath the legrest has to be unlocked (moved to the right)
in order to move the legrest with the backrest. Support the legrest with your
other hand when locking or unlocking the lever.
1. Automatic legrest
2. Lever
The automatic legrest can be locked approximately 18° from the horizontal
position. To lock the legrest, the lever has to be moved to the left. Support
the legrest with your other hand when locking or unlocking the lever. Notice
that the backrest will move upward and downward when the legrest is
locked.
1. Approx. 18° from the horizontal position
2. Lever
12 Patient chair
64 Planmeca Compact i User's manual
