Humidity: dew point not greater than −20 °C at atmospheric
pressure
Quality: medical grade, dry and oil-free
Oil contamination:
max. 0.5 mg/m
3
Particulate
contamination:
≤ 100 particles per cubic meter for 1 μm to 5 μm
particle size
Connection: 1/4”
Water and air filters
Water filter: 25 µm (internal), 5 µm (external suggested)
Air filter: 25 µm (internal)
Replacement of water and air filters should be performed by qualified
service technician according to the maintenance schedule.
See section "Annual maintenance" on page 6.
Suction connection
Vacuum: ≥ 150 mbar
Flow rate: ≥ 550 l/ min
Connection: Ø 50 / 46 mm
Type: Medium volume
Class: Wet or dry depending on installed options
Drain connection
Capacity: min. 10 l/min
Connection: Ø 50 / 46 mm
Water and air quick-connectors (optional)
Output pressure: water 2.8 bar, air 5.5 bar (regulated internal water
and air pressure
Foot control power supply (optional)
Type: MENB1010A0903F01
Wireless foot control (optional)
Battery size: AA, HR6
Battery type: NiMH 1.2V, min 2000mAh, low self-discharge,
UL-listed (USA, Canada only)
Planmeca ProSensor power supply (optional)
Phihong Single Port Injector
Type: PSA16U-480 (POE)
Input voltage: 100-240 VAC (50-60 Hz)
Output voltage: 48VDC
Max. output current: 0.35 A
Insulation voltage
Primary-secondary 3000VDC
34 Technical information
User's manual Planmeca Compact i 289
