4. Place the clean-water bottle back in its place in the dental unit.
NOTE
Ensure that the water supply switch is turned toward ‘BOTTLE’ and that
the water bottle switch is turned toward ‘ON’.
5. Press Maintenance to go into maintenance mode.
NOTE
To be able to run the short instrument flushing cycle from the
Maintenance window you need an instrument flushing holder. If you do
not have the holder, skip this step.
6. Remove the instrument handpieces from the instruments and clean them
according to the manufacturer’s instructions.
7. Place all water consuming instruments (including syringes) into the
openings in the instrument flushing holder.
NOTE
If you do not have an instrument flushing holder, skip this step.
Optionally, in dental units with balanced instrument arms, you can
remove the hoses of the instruments to be flushed from the instrument
arms / instrument holders before placing the instruments in the flushing
holder.
In dental units with hanging-tube instruments, the instruments to be
flushed must be removed from the instrument holders before placing
them in the flushing holder.
1 Flushing holder cover
Each type of syringe has its dedicated place in the flushing holder. The
DCI and Luzzani Minibright syringes require an adapter that must be
placed in the instrument flushing holder to keep the syringe in place. The
picture below shows an example of how the syringes can be placed, but
note that the picture does not represent the actual holder.
28 Clean water system
196 Planmeca Compact i3 User's manual
