Planmeca Compact i3 User Manual

Instrument multiplexer related error messages
ERROR
CODE
EXPLANATION
E35.1 Drive/Cooling air pressure sensor output <0.2 V.
E35.2 Air coolant pressure sensor output <0.2 V.
E35.3 Water coolant pressure sensor output <0.2 V.
E35.4 Differential pressure sensor output <0.2 V.
E36.1 Drive/Cooling air measurement over range.
Check if micromotor handpiece has air- and waterlines. Check
if instrument, handpiece or hose is blocked.
E36.2 Spray air measurement over range.
Check if micromotor handpiece has air- and waterlines. Switch
off spray water and air if there are no air- and waterlines in
instrument or handpiece.
E36.3 Spray water measurement over range.
Check if micromotor handpiece has air- and waterlines. Switch
off spray water and air if there are no air- and waterlines in
instrument or handpiece.
E36.4 Differential pressure sensor output >5 V.
E37 Pressure sensor cable not properly attached to IMUX.
E39 Drive (cooling) air valve control servo cannot maintain
pressure to instrument.
E42 Air coolant (spray air) control servo cannot maintain required
pressure.
E45 Water coolant (spray water) control servo cannot maintain
required pressure.
29.3.6 Suction holder related error messages
Suction holder related error messages
ERROR
CODE
EXPLANATION
E47 Suction holder is of new type.
E47.1 Suction holder in branch 1 is of new type.
Update MCB software.
E47.2 Suction holder in branch 2 is of new type.
Update MCB software.
E48.1 No suction holders detected.
Either the holder is missing or faulty, or the cable to the holder
is loose or faulty.
E48.2 Suction holder related error messages.
E48.3 Suction holder related error messages.
E48.4 Suction holder related error messages.
29 Help and error messages
User's manual Planmeca Compact i3 217
