Help messages
HELP
CODE
MEANING ACTION OR EXPLANATION
FC.RD Move foot control pedal to rightmost
position. Press pedal down and hold. While
holding, push centre knob briefly in 'chair up'
direction.
Move the foot control pedal to the rightmost
position. Press the pedal down and hold.
While holding, push the centre knob briefly
in the ‘chair up’ direction.
FC.RU Move foot control pedal to rightmost position
and hold. While holding, push centre knob
briefly in 'chair up' direction.
Move the foot control pedal to the rightmost
position and hold. While holding, push the
centre knob briefly in the ‘chair up’ direction.
FC.-- To exit foot control calibration mode, press
and hold down calibration switch for 4
seconds.
H 7003 Control panel is temporarily disabled due to
interference on touch screen.
Make sure the touch screen is clean and
dry. If the problem continues, contact
service.
29.3 Error messages in short form
29.3.1 General error messages
General error messages
ERROR
CODE
EXPLANATION
E1.01 Main water valve short circuit.
Disconnect valve and check if error disappears.
E1.02 Main air valve short circuit.
Disconnect valve and check if error disappears.
E1.03 Bowl rinse valve short circuit.
Disconnect valve and check if error disappears.
E1.04 Cup filling valve short circuit.
Disconnect valve and check if error disappears.
E1.05 Water flush valve short circuit.
Disconnect valve and check if error disappears.
E1.06 Separator pulse valve short circuit.
Disconnect valve and check if error disappears.
E1.07 Ejector valve short circuit.
Disconnect valve and check if error disappears.
E1.08 Extra out 1 short circuit.
Disconnect output and check if error disappears.
E1.09 Extra out 2 short circuit.
Disconnect output and check if error disappears.
E1.10 Extra out 3 short circuit.
Disconnect output and check if error disappears.
29 Help and error messages
User's manual Planmeca Compact i3 211
