Planmeca Compact i3 User Manual

Connection: 1/4”
Water and air filters
Water filter: 25 µm (internal), 5 µm (external suggested)
Air filter: 25 µm (internal)
Replacement of water and air filters should be performed by qualified
service technician according to the maintenance schedule.
See section "Annual maintenance" on page 6.
Suction connection
Vacuum: ≥ 150 mbar
Flow rate: ≥ 550 l/ min
Connection: Ø 50 / 46 mm
Type: Medium volume
Class: Wet
32.2 Instrument classifications
The electrical classification of the instrument is marked on the instrument
hose either as B or BF. If there is no marking, no electricity flows through the
instrument.
Type B
Type BF
The following lists the instruments that are available for the Planmeca dental
unit and their electrical classification type.
Instrument classifications
Instrument Type
DCI autoclavable 3-way syringe B
Luzzani Ergo 3-way syringe B
Luzzani Minibright 6-way syringe B
Luzzani Minibright 6-way syringe with LED B
PM fibre optic turbine hose S B
Bien-Air MCX brushless micromotor with LED B
Bien-Air MX2 brushless micromotor with LED B
Planmeca Minetto brushless micromotor with LED B
Morita TORX micromotor B
EMS No Pain scaler B
EMS No Pain LED scaler B
32 Technical information
234 Planmeca Compact i3 User's manual
