Planmeca Compact i3 User Manual

2. Lifting mechanism safety bar
An obstruction between the lifting mechanism safety bar and the floor
stops downwards chair and backrest movements. Remove the
obstruction to resume normal operation.
3. Suction module bottom cover
An obstruction between the suction module bottom and the chair lifting
mechanism stops downwards chair and backrest movements. Remove
the obstruction to resume normal operation.
4. Suction arm safety bar
An obstruction between the suction arm and the floor prevents the chair
and backrest from being driven downward. Remove the obstruction to
resume normal operation.
5. Seat bottom cover
An obstruction between the chair and the floor stops downwards chair
and backrest movements. Remove the obstruction to resume normal
operation.
6. Backrest
An obstruction between the backrest and the floor when driving down the
chair and/or the backrest stops downwards chair and backrest
movements. Remove the obstruction to resume normal operation.
7. Adapter tube bottom cover
An obstruction between the adapter tube bottom cover and the chair
lifting mechanism when driving down the chair stops downwards chair
and backrest movements. Remove the obstruction to resume normal
operation.
7.3 Stopping chair movements quickly
The chair movements can be stopped quickly by:
• touching anywhere on the control panel display,
• pressing any chair button on the Flexy-holder,
• kicking any safety switch,
• pushing the foot control pedal or the centre knob in any direction, or by
7 For your safety
User's manual Planmeca Compact i3 13
