Planmeca Compact i3 User Manual

13 Control panel
13.1 Control panel on instrument console
1. Sign out button 10. Bluetooth connection enabled (optional,
display only)
2. Patient recognition (display only) 11. Timer button
3. Time (display only) 12. X-ray film viewer button
4. Date (if configured, display only) 13. Unit buttons
5. Maintenance button 14. Customisable swipe menu. Swipe to the side
to view more functions
6. Assistant call / Door open 15. Touchpad button (optional)
7. Chair buttons 16. Solanna Vision button (optional)
8. User name (display only) 17. Apex locator button (optional)
9. Romexis connection (optional, display only) 18. Program button
The control panel is located on the instrument console. You can use it to
control and program the instruments, the dental unit, and the chair. You can
also start maintenance procedures from the control panel.
You can operate the control panel by touching it with your finger or with a
soft stylus. The display is generally medical glove touch capable, but some
glove types have limited functionality.
The control panel shows information related to the current operation and
changes accordingly.
13 Control panel
52 Planmeca Compact i3 User's manual
