29.3.16 Error messages generated by control panel

Error messages generated by control panel

ERROR

CODE

EXPLANATION

EP19.3 Control panel version mismatch.

EP19.5 Control panel software upgrade has failed or memory card is

faulty.

EP21.1 Control panel display is faulty.

EP21.2 Control panel data error.

EP21.5 Unable to read Main PCB software version.

EP21.6 Control panel software not installed or software error.

Insert software update SD-card or contact service.

EP21.7 Touch panel is not working.

29.4 Viewing help and error message history

About this task

The dental unit keeps a log of all help and error messages. It can be viewed

in the

About this unit

window.

Steps

1. Press Program.

29 Help and error messages

User's manual Planmeca Compact i3 223
