Scaler
Action Function
Pedal left / pedal right Drive instrument
Pedal down, short activation Change spray 1 / 2 / off
Unit controlled polymerisation light
Action Function
Pedal left / pedal right / pedal down Start / stop instrument
Intraoral camera
Action Function
Pedal left / pedal right Freeze / unfreeze picture
Pedal down Save still picture
Intraoral scanner
Action Function
Pedal left Move upward in the list of scan type selection tools
Pedal right Move downward in the list of scan type selection tools
Pedal down, short activation Start scanning
Pedal down, long activation Take image
14 Foot control
User's manual Planmeca Compact i3 59
