Planmeca ProMax Technical Manual

6 Planmeca ProMax
TABLE OF CONTENTS
Technical Manual
Planmeca pursues a policy of continual product development. Although every effort is
made to produce up-to-date product documentation this publication should not be re-
garded as an infallible guide to current specifications. We reserve the right to make
changes without prior notice.
COPYRIGHT PLANMECA
Released: 1 August 2013
Publication part number: 10010812 revision 31
The manufacturer, assembler, and importer are responsible for the safety, reliability and
performance of the X-ray unit only if:
- installation, calibration, modification and repairs are carried out by qualified author-
ized personnel
- electrical installations are carried out according to the appropriate requirements such
as IEC 60364
- equipment is used according to the operating instructions
5.1 Cephalostat connector PCB..................................................................... H-67
Chapter I PLANMECA PROCEPH
1 ADJUSTMENTS AND CALIBRATIONS ........................................................I-1
1.1 Required tools .............................................................................................. I-1
1.2 Removing the necessary covers .................................................................. I-2
1.3 Parameter values and beam check exposure.............................................. I-2
1.4 Adjusting the height of the cephalostat ........................................................ I-6
1.5 Checking the cephalostat head support position ......................................... I-8
1.6 Calibrating the left side of the cephalometric X-ray beam.......................... I-10
1.7 Cephalostat head support adjustments...................................................... I-11
1.8 Adjusting the cephalometric beam top limit................................................ I-14
1.9 Calibrating the right side of the X-ray beam............................................... I-16
1.10 Checking the adjustment............................................................................ I-17
2 REMOVING THE HOUSINGS AND COVERS ...........................................I-18
2.1 Removing the housings of the head support.............................................. I-18
Chapter J DIAGRAMS

Planmeca ProMax Specifications

General

Category	Medical Equipment
Type	Cone Beam Computed Tomography (CBCT) System
Software	Planmeca Romexis
Imaging Modes	CBCT
Imaging Modalities	2D Panoramic
X-ray Generator	High Frequency Generator
Focal Spot Size	0.5 mm
X-ray Tube Voltage	60-90 kV
Exposure Time	Varies depending on imaging mode and parameters
Dimensions	Varies significantly depending on model and configuration
Weight	Varies significantly depending on model and configuration
Power Requirements	50/60 Hz
Patient Positioning	seated
