9924707 - 2013–2014 RZR 800 Service Manual
© Copyright 2013 Polaris Sales Inc.
DIAGNOSTIC TROUBLE CODE TABLE
Component
Condition SPN FMI
Digital
Wrench® P-
Code
Steering Excessive Current Error
Current Above Normal or Grounded 520222 6 C1051
Steering Torque Partial Failure
Condition Exists 520223 31 C1052
Steering Torque Full Failure
Condition Exists 520224 31 C1053
EPS Inverter Temperature
Greater than 110° C (230° F)
520225
16 C1054
Greater than 120° C (248° F)
0 C1055
EPS CAN Communications
Receive Error
No RX Message for 2 Seconds
520226 2 U0100
EPS CAN Communications
Transmit Error
No TX Message for 2 Seconds
520227 2 U1100
Position Encoder Error Position Encoder Error 520228 11 C1065
EPS Software Error Software Error 520229 12 C1070
IC CAN Communication with EPS
EPS Off Line (EPS DM1 not seen)
520230 31 U0131
EPS Power Save Condition
EPS: Key On, Engine Off, 5 Minute Power
Save/Timeout
520231 31 C1071
Idle Air Control Valve (IAC)
M17; IAC Stepper Pin 3
Driver Circuit Open / Grounded
520268
5 P1515
Driver Circuit Short to B+ 3 P1519
Driver Circuit Grounded 4 P1518
Idle Air Control Valve (IAC)
M17; IAC Stepper Pin 4
Driver Circuit Open / Grounded
520269
5 P1525
Driver Circuit Short to B+ 3 P1529
Driver Circuit Grounded 4 P1528
Idle Air Control Valve (IAC)
M17; IAC Stepper Pin 6
Driver Circuit Open / Grounded
520270
5 P1535
Driver Circuit Short to B+ 3 P1539
Driver Circuit Grounded 4 P1538
Idle Air Control Valve (IAC)
M17; IAC Stepper Pin 1
Driver Circuit Open / Grounded
520271
5 P1505
Driver Circuit Short to B+ 3 P1509
Driver Circuit Grounded 4 P1508
ELECTRONIC FUEL INJECTION
