DIAGNOSTIC TROUBLE CODE TABLE
Component
Condition SPN FMI
Digital
Wrench® P-
Code
C1064
Engine Speed (This is applicable
when the EPS module gets the
engine speed from the ECM)
Engine Speed Too High
190
0 C1059
Received Engine Speed Has Error
19 C1066
Gear Sensor Signal Voltage Too Low
523 4 P0916
ECU Memory
EEPROM: Read/Write Failure 628 12 C1073
Calibration Checksum/CRC Error 630 13 C1074
Crankshaft Position Sensor (CPS) Plausibility Fault
636 2 P0335
Camshaft Phase Sensor Circuit Fault 637 8 P0340
Injector 1 (MAG)
Driver Circuit Open / Grounded
651
5 P0261
Driver Circuit Short to B+ 3 P0262
Driver Circuit Grounded 4 P1262
Injector 2 (PTO)
Driver Circuit Open / Grounded
652
5 P0264
Driver Circuit Short to B+ 3 P0265
Driver Circuit Grounded 4 P1265
Rear Differential Output
Driver Circuit Open / Grounded
746
5 P1691
Driver Circuit Short to B+ 3 P1692
Driver Circuit Grounded 4 P1693
Fan Relay Driver Circuit
Driver Circuit Open / Grounded
1071
5 P1481
Driver Circuit Short to B+ 3 P1482
Driver Circuit Grounded 4 P1483
Ignition Coil Primary Driver 1 (MAG)
Driver Circuit Short to B+ 1268 3 P1353
Ignition Coil Primary Driver 2 (PTO)
Driver Circuit Short to B+ 1269 3 P1354
Fuel Pump Driver Circuit
Driver Circuit Open / Grounded
1347
5 P0230
Driver Circuit Short to B+ 3 P0232
Driver Circuit Grounded 4 P0231
ECU Output Supply Voltage 1
Voltage Too High
3597
3 P16A2
Voltage Too Low
4 P16A1
ECU Output Supply Voltage 2
Voltage Too High
3598
3 P16A9
Voltage Too Low
4 P16A8
Throttle Release Signal
Voltage Too High
520194
3 P1555
Voltage Too Low
4 P1554
Throttle Stuck 7 P1552
All Wheel Drive Control Circuit
(AWD)
Driver Circuit Open / Grounded
520207
5 P1836
Driver Circuit Short to B+ 3 P1835
Driver Circuit Grounded 4 P1834
Steering Over Current Shut Down
Current Above Normal or Grounded 520221 6 C1050
