Operator’s Manual LTV
®
Series ventilator Page 6-15
p/n 10664, Rev. Y
Low Pressure O
2
Source (cont)
Low Pressure O
2
Blending:
Oxygen will be applied through the low pressure, low flow inlet. Use this chart to determine the
approximate O
2
flow required to deliver the desired FIO
2
.
WARNING
Inspired Oxygen (FIO
2
) Concentration – If the patient has a variable respiratory rate, his/her minute
ventilation will fluctuate. If exact concentrations of inspired oxygen (FIO
2
) are required to be delivered
to the patient, it is recommended that an accurate oxygen analyzer with alarms be used.
AVERTISSEMENT
Concentration d’oxygène inspiré (FIO
2
) – Si la fréquence respiratoire du patient est variable, sa
ventilation-minute va fluctuer. Lorsqu’une concentration exacte d’oxygène inspiré (FIO
2
) est
nécessaire pour une transmission au patient, il est recommandé d’utiliser un analyseur de niveau
d’oxygène précis, comportant des alarmes.
