Parameter List
11
11.3 b: APPLICATION
SIEPYEUOQ2A01G AC Drive Q2A Technical Manual 421
No.
(Hex.)
Name Description
Default
(Range)
Ref.
b5-53
(0B8F)
RUN
PID I Ramp Limit
Sets the responsiveness of PID control when the PID feedback changes quickly.
0.0 Hz
(0.0 - 10.0 Hz)
572
b5-55
(0BE1)
PID Fback Mon
Selection
Sets the monitor for PID Feedback (Ux-xx).
000
(000 - 999)
572
b5-56
(0BE2)
PID FdbkMon Gain
Sets the gain for the monitor specified in b5-55 [PID Fback Mon Selection].
1.00
(0.00 - 10.00)
572
b5-57
(11DD)
PID FdbkMon Bias
Sets the bias for the monitor specified in b5-55 [PID Fback Mon Selection].
0.00
(-10.00 - +10.00)
572
b5-58 to b5-60
(1182 - 1184)
RUN
PID Setpoint 2 to PID
Setpoint 4
Sets the PID setpoint when H1-xx = 77 or 78 [MFDI Function Select = PID SP
Selection 1/2]. This value is a percentage where E1-04 [Max Output Frequency] setting
= a setting value of 100%.
0.00%
(0.00 - 100.00%)
572
b5-61
(119A)
PID LoLim Select for
Trim Mode
Sets the function that adjusts the PID output in relation to the frequency reference.
0 : Disabled
1 : Enabled
0
(0, 1)
573
b5-62
(119B)
PID LoLim Value for
Trim Mode
Sets the lower limit of the PID frequency reference trim as a percentage where E1-04
[Max Output Frequency] setting = a setting value of 100%.
0.00%
(0.00 - 100.00%)
573
b5-63
(119C)
PID DifFB Mon
Selection
Sets the monitor for PID Differential Feedback (Ux-xx).
000
(000 - 999)
573
b5-64
(119D)
PID DifFB Mon Gain
Sets the gain for the monitor specified in b5-63 [PID DifFB Mon Selection].
1.00
(0.00 - 10.00)
573
b5-65
(119F)
PID DifFB Mon Bias
Sets the bias for the monitor specified in b5-63 [PID DifFB Mon Selection].
0.00
(-10.00 - +10.00)
573
b5-66
(11DE)
PID Fback Mon Level
Sets the signal level for the monitor specified in b5-55 [PID Fback Mon Selection].
0 : Absolute
1 : Bi-directional (+/-)
0
(0, 1)
574
b5-67
(11DF)
PID DifFB Mon Level
Sets the signal level for the monitor specified in b5-63 [PID DifFB Mon Selection].
0 : Absolute
1 : Bi-directional (+/-)
0
(0, 1)
574
b5-89
(0B89)
RUN
Sleep Method Selection
Sets sleep and wake up operation when using PID.
0 : Standard
1 : EZ Sleep/Wake-up
0
(0, 1)
574
b5-90
(0B90)
EZsleep Unit
Sets the measurement units for b5-91 [EZsleep Min Spd] and b5-92 [EZsleep Level].
0 : rpm
1 : 0.1Hz units
1
(0, 1)
574
b5-91
(0B91)
RUN
EZsleep Min Spd
Sets the minimum speed for the EZ Sleep/Wakeup function. This parameter uses the
largest value from b5-91, b5-34 [PID Out Low Limit Level], and d2-02 [FRef Lower
Limit].
0.0 Hz or 0 rpm (r/min)
(0.0 to 590.0 Hz or 0 to
35400 rpm (r/min))
574
b5-92
(0B92)
RUN
EZsleep Level
Sets the value that the output frequency or motor speed must be less than for longer than
b5-93 [EZsleep Time] to enter Sleep Mode.
0.0 Hz or 0 rpm (r/min)
(0.0 to 590.0 Hz or 0 to
35400 rpm (r/min))
574
b5-93
(0B93)
RUN
EZsleep Time
Sets the length of time that the output frequency or motor speed must be less than b5-92
[EZsleep Level] to enter Sleep Mode.
5.0 s
(0.0 - 1000.0 s)
575
b5-94
(0B94)
RUN
EZsleep Wake Level
Sets the level at which the drive resumes operation when exiting Sleep Mode.
0.00%
(0.00 - 600.00%)
575
b5-95
(0B95)
EZsleep Wake Mode
Sets the wake-up mode to use when exiting Sleep Mode.
0 : Setpoint Delta
1 : Absolute
1
(0, 1)
575
b5-96
(0B96)
EZsleep Wake Time
Sets the EZ Wake-up time.
1.0 s
(0.0 - 1000.0 s)
575
