11.20 Parameters Changed by PM Motor Code Selection
522 SIEPYEUOQ2A01G AC Drive Q2A Technical Manual
No. Name Unit Motor Code (setting value of E5-01)
E5-06
PM d-Axis Inductance
(mH/Phase)
mH 113.84 77.84 40.00 27.52 31.73 23.09 25.28 13.36
E5-07
PM q-Axis Inductance
(mH/Phase)
mH 157.16 103.56 60.80 37.00 40.88 34.39 35.20 18.44
E5-09
PM BackEMF Vpeak
(mV/(rad/ s))
mVs/rad 490.8 513.8 543.7 520.3 580.8 602.7 601.5 584.6
E5-24
PM BackEMF L-L
Vrms (mV/rpm)
mV/(r/
min)
0.0 0.0 0.0 0.0 0.0 0.0 0.0 0.0
E1-04 Max Output Frequency Hz 72.5 72.5 72.5 72.5 72.5 72.5 72.5 72.5
E1-05 Max Output Voltage V 380.0 380.0 380.0 380.0 380.0 380.0 380.0 380.0
E1-06 Base Frequency Hz 72.5 72.5 72.5 72.5 72.5 72.5 72.5 72.5
E1-09 Min Output Frequency Hz 3.6 3.6 3.6 3.6 3.6 3.6 3.6 3.6
C5-17 Motor Inertia kgm
2
0.0016 0.0022 0.0081 0.0133 0.0133 0.017 0.027 0.044
L3-24
*1
Acc@Rated Torque s 0.092 0.068 0.125 0.139 0.083 0.070 0.082 0.092
n5-02
Mot Inertia
Acceleration Time
s 0.092 0.068 0.125 0.139 0.083 0.070 0.082 0.092
n8-49 Heavy Load Id Current % -9.5 -9.4 -13.7 -10.0 -12.9 -19.9 -22.8 -19.8
*1 Default settings vary depending on the setting of o2-04 [Drive KVA Selection].
Table 11.17 SST4 Series Motor Code Setting for Specification of 400 V at 1450 min
-1
(r/min)
No. Name Unit Motor Code (setting value of E5-01)
E5-01
PM Mot Code Selection - 233E 233F 2340 2342 2343 2344 2345 2346
Voltage Class V 400 400 400 400 400 400 400 400
Capacity kW 15 18 22 30 37 45 55 75
Motor Rotation Speed min
-1
1450 1450 1450 1450 1450 1450 1450 1450
E5-02
PM Mot Rated Power
(kW)
kW 15 18.50 22.00 30.00 37.00 45.00 55.00 75.00
E5-03
PM Mot Rated Current
(FLA)
A 27.1 34.2 37.6 50.9 65.4 80.2 96.1 129.2
E5-04 PM Mot Pole Count - 6 6 6 6 6 6 6 6
E5-05
PM Mot Resistance
(Ohms/Phase)
Ω 0.291 0.220 0.192 0.136 0.091 0.064 0.048 0.028
E5-06
PM d-Axis Inductance
(mH/Phase)
mH 11.77 8.94 8.32 6.68 5.30 3.76 3.09 2.24
E5-07
PM q-Axis Inductance
(mH/Phase)
mH 14.60 11.40 10.64 8.16 6.80 4.88 4.75 3.03
E5-09
PM BackEMF Vpeak
(mV/(rad/ s))
mVs/rad 610.3 595.2 711.6 710.8 652.7 604.8 669.1 646.8
E5-24
PM BackEMF L-L
Vrms (mV/rpm)
mV/(r/
min)
0.0 0.0 0.0 0.0 0.0 0.0 0.0 0.0
E1-04 Max Output Frequency Hz 72.5 72.5 72.5 72.5 72.5 72.5 72.5 72.5
E1-05 Max Output Voltage V 380.0 380.0 380.0 380.0 380.0 380.0 380.0 380.0
E1-06 Base Frequency Hz 72.5 72.5 72.5 72.5 72.5 72.5 72.5 72.5
E1-09 Min Output Frequency Hz 3.6 3.6 3.6 3.6 3.6 3.6 3.6 3.6
C5-17 Motor Inertia kgm
2
0.054 0.063 0.113 0.137 0.252 0.304 0.41 0.55
L3-24
*1
Acc@Rated Torque s 0.083 0.079 0.118 0.105 0.157 0.156 0.172 0.169
n5-02
Mot Inertia
Acceleration Time
s 0.083 0.079 0.118 0.105 0.157 0.156 0.172 0.169
n8-49 Heavy Load Id Current % -14.5 -16.1 -11.8 -10.5 -15.6 -17.4 -21.7 -17.3
*1 Default settings vary depending on the setting of o2-04 [Drive KVA Selection].
