Q2 Q2A User Manual

Parameter List
11
11.20 Parameters Changed by PM Motor Code Selection
SIEPYEUOQ2A01G AC Drive Q2A Technical Manual 523
Table 11.18 SST4 Series Motor Code Setting for Specification of 400 V at 1450 min
-1
(r/min)
No. Name Unit Motor Code (setting value of E5-01)
E5-01
PM Mot Code Selection - 2347 2348 2349 234A 234C 234D
Voltage Class V 400 400 400 400 400 400
Capacity kW 90 110 132 160 200 250
Motor Rotation Speed min
-1
1450 1450 1450 1450 1450 1450
E5-02
PM Mot Rated Power
(kW)
kW 90.00 110.00 132.00 160.00 200.00 250.00
E5-03
PM Mot Rated Current
(FLA)
A 153.1 191.7 226.0 268.8 331.3 422.9
E5-04 PM Mot Pole Count - 6 6 6 6 6 6
E5-05
PM Mot Resistance
(Ohms/Phase)
Ω 0.024 0.015 0.011 0.007 0.006 0.003
E5-06
PM d-Axis Inductance
(mH/Phase)
mH 2.20 1.34 1.23 0.92 0.84 0.61
E5-07
PM q-Axis Inductance
(mH/Phase)
mH 3.23 2.16 1.67 1.30 1.25 0.89
E5-09
PM BackEMF Vpeak
(mV/(rad/ s))
mVs/rad 708.0 637.8 677.0 661.7 687.1 655.9
E5-24
PM BackEMF L-L
Vrms (mV/rpm)
mV/(r/
min)
0.0 0.0 0.0 0.0 0 0.0
E1-04 Max Output Frequency Hz 72.5 72.5 72.5 72.5 72.5 72.5
E1-05 Max Output Voltage V 380.0 380.0 380.0 380.0 380.0 380.0
E1-06 Base Frequency Hz 72.5 72.5 72.5 72.5 72.5 72.5
E1-09 Min Output Frequency Hz 3.6 3.6 3.6 3.6 3.6 3.6
C5-17 Motor Inertia kgm
2
0.82 0.96 1.60 1.95 2.82 3.70
L3-24
*1
Acc@Rated Torque s 0.210 0.201 0.279 0.281 0.325 0.341
n5-02
Mot Inertia
Acceleration Time
s 0.210 0.201 0.279 0.281 0.325 0.341
n8-49 Heavy Load Id Current % -19.6 -24.1 -15.1 -17.0 -19.8 -19.3
*1 Default settings vary depending on the setting of o2-04 [Drive KVA Selection].
Table 11.19 SST4 Series Motor Code Setting for Specification of 400 V at 1150 min
-1
(r/min)
No. Name Unit Motor Code (setting value of E5-01)
E5-01
PM Mot Code Selection - 2432 2433 2435 2436 2438 243A 243B
Voltage Class V 400 400 400 400 400 400 400
Capacity kW 0.4 0.75 1.5 2.2 3.7 5.5 7.5
Motor Rotation Speed min
-1
1150 1150 1150 1150 1150 1150 1150
E5-02
PM Mot Rated Power
(kW)
kW 0.4 0.75 1.5 2.2 3.7 5.5 7.5
E5-03
PM Mot Rated Current
(FLA)
A 0.89 1.72 3.02 4.58 7.40 10.21 13.75
E5-04 PM Mot Pole Count - 6 6 6 6 6 6 6
E5-05
PM Mot Resistance
(Ohms/Phase)
Ω 10.720 6.080 4.336 2.143 1.428 1.199 0.648
E5-06
PM d-Axis Inductance
(mH/Phase)
mH 122.20 61.16 70.24 46.20 33.87 41.67 21.24
E5-07
PM q-Axis Inductance
(mH/Phase)
mH 170.80 97.12 90.04 60.28 42.98 69.15 33.04
E5-09
PM BackEMF Vpeak
(mV/(rad/ s))
mVs/rad 626.1 626.1 703.1 727.6 699.0 861.5 759.7
E5-24
PM BackEMF L-L
Vrms (mV/rpm)
mV/(r/
min)
0.0 0.0 0.0 0.0 0.0 0.0 0.0
E1-04 Max Output Frequency Hz 57.5 57.5 57.5 57.5 57.5 57.5 57.5
E1-05 Max Output Voltage V 380.0 380.0 380.0 380.0 380.0 380.0 380.0
E1-06 Base Frequency Hz 57.5 57.5 57.5 57.5 57.5 57.5 57.5
E1-09 Min Output Frequency Hz 2.9 2.9 2.9 2.9 2.9 2.9 2.9
