11.20 Parameters Changed by PM Motor Code Selection
524 SIEPYEUOQ2A01G AC Drive Q2A Technical Manual
No. Name Unit Motor Code (setting value of E5-01)
C5-17 Motor Inertia kgm
2
0.0022 0.0042 0.0081 0.0133 0.0168 0.027 0.044
L3-24
*1
Acc@Rated Torque s 0.080 0.081 0.078 0.088 0.066 0.070 0.085
n5-02
Mot Inertia Acceleration
Time
s 0.080 0.081 0.078 0.088 0.066 0.070 0.085
n8-49 Heavy Load Id Current % -8.4 -11.0 -9.9 -9.0 -11.4 -23.2 -22.1
*1 Default settings vary depending on the setting of o2-04 [Drive KVA Selection].
Table 11.20 SST4 Series Motor Code Setting for Specification of 400 V at 1150 min
-1
(r/min)
No. Name Unit Motor Code (setting value of E5-01)
E5-01
PM Mot Code Selection - 243D 243E 243F 2440 2442 2443 2444
Voltage Class V 400 400 400 400 400 400 400
Capacity kW 11 15 18 22 30 37 45
Motor Rotation Speed min
-1
1150 1150 1150 1150 1150 1150 1150
E5-02
PM Mot Rated Power
(kW)
kW 11.0 15 18.50 22.00 30.00 37.00 45.00
E5-03
PM Mot Rated Current
(FLA)
A 19.5 27.7 32.7 39.2 51.8 63.0 76.6
E5-04 PM Mot Pole Count - 6 6 6 6 6 6 6
E5-05
PM Mot Resistance
(Ohms/Phase)
Ω 0.460 0.325 0.260 0.209 0.140 0.106 0.076
E5-06
PM d-Axis Inductance
(mH/Phase)
mH 17.76 12.83 11.68 10.09 8.12 6.43 4.96
E5-07
PM q-Axis Inductance
(mH/Phase)
mH 22.72 17.19 15.16 16.25 9.84 7.71 6.56
E5-09
PM BackEMF Vpeak
(mV/(rad/ s))
mVs/rad 740.4 716.6 809.1 786.2 888.8 857.7 941.6
E5-24
PM BackEMF L-L
Vrms (mV/rpm)
mV/(r/
min)
0.0 0.0 0.0 0.0 0.0 0.0 0.0
E1-04 Max Output Frequency Hz 57.5 57.5 57.5 57.5 57.5 57.5 57.5
E1-05 Max Output Voltage V 380.0 380.0 380.0 380.0 380.0 380.0 380.0
E1-06 Base Frequency Hz 57.5 57.5 57.5 57.5 57.5 57.5 57.5
E1-09 Min Output Frequency Hz 2.9 2.9 2.9 2.9 2.9 2.9 2.9
C5-17 Motor Inertia kgm
2
0.054 0.063 0.113 0.137 0.252 0.304 0.410
L3-24
*1
Acc@Rated Torque s 0.071 0.061 0.089 0.090 0.122 0.119 0.132
n5-02
Mot Inertia Acceleration
Time
s 0.071 0.061 0.089 0.090 0.122 0.119 0.132
n8-49 Heavy Load Id Current % -16.7 -20.2 -15.2 -27.7 -9.8 -10.2 -11.5
*1 Default settings vary depending on the setting of o2-04 [Drive KVA Selection].
Table 11.21 SST4 Series Motor Code Setting for Specification of 400 V at 1150 min
-1
(r/min)
No. Name Unit Motor Code (setting value of E5-01)
E5-01
PM Mot Code Selection - 2445 2446 2447 2448 2449 244A 244C
Voltage Class V 400 400 400 400 400 400 400
Capacity kW 55 75 90 110 132 160 200
Motor Rotation Speed min
-1
1150 1150 1150 1150 1150 1150 1150
E5-02
PM Mot Rated Power
(kW)
kW 55.00 75.00 90.00 110.00 132.00 160.00 200.00
E5-03
PM Mot Rated Current
(FLA)
A 93.1 128.1 153.1 186.5 221.9 269.8 336.5
E5-04 PM Mot Pole Count - 6 6 6 6 6 6 6
E5-05
PM Mot Resistance
(Ohms/Phase)
Ω 0.051 0.032 0.026 0.015 0.012 0.009 0.007
E5-06
PM d-Axis Inductance
(mH/Phase)
mH 3.99 2.97 2.44 1.87 1.49 1.41 1.22
