12.7 H: TERMINALS
694 SIEPYEUOQ2A01G AC Drive Q2A Technical Manual
■ 9: Ext Ref 1/2
Setting Function Description
9 Ext Ref 1/2
Sets the drive to use Run command source 1/2 or Reference command source 1/2 when in REMOTE Mode.
Note:
When the drive is receiving a Run command, you cannot switch between reference sources.
ON : b1-15 [Freq. Ref. Sel. 2], b1-16 [Run Comm. Sel 2]
OFF : b1-01 [Freq. Ref. Sel. 1], b1-02 [Run Comm. Sel 1]
■ A: MultSpd Ref1
Setting Function Description
A MultSpd Ref1
Uses speed references d1-01 to d1-08 [Reference 1 to Reference 8] to set a multi-step speed reference.
Note:
Refer to “Setting Procedures for Multi-step Speed Operation” in “d: REFERENCE” for more information.
■ B: MultSpd Ref2
Setting Function Description
B MultSpd Ref2
Uses speed references d1-01 to d1-08 [Reference 1 to Reference 8] to set a multi-step speed reference.
Note:
Refer to “Setting Procedures for Multi-step Speed Operation” in “d: REFERENCE” for more information.
■ C: MultSpd Ref3
Setting Function Description
C MultSpd Ref3
Uses speed references d1-01 to d1-08 [Reference 1 to Reference 8] to set a multi-step speed reference.
Note:
Refer to “Setting Procedures for Multi-step Speed Operation” in “d: REFERENCE” for more information.
■ D: MultSpd Ref4
Setting Function Description
D MultSpd Ref4
Sets the command to switch d1-09 to d1-16 [Reference 9 to Reference 16] with multi-step speed references 1, 2 and 3.
Note:
Refer to “Setting procedure for the multi-step speed operation” for more information.
■ E: Offset Frq 1
Setting Function Description
E Offset Frq 1
Sets the function to add the offset frequency set in d7-01 [Offset Frq 1] to the frequency reference when the terminal activates.
Note:
Refer to “d7: OFFSET FREQUENCY” for more information.
■ F: Offset Frq 2
Setting Function Description
F Offset Frq 2
Sets the function to add the offset frequency set in d7-02 [Offset Frq 2] to the frequency reference when the terminal activates.
Note:
Refer to “d7: OFFSET FREQUENCY” for more information.
