Parameters:
<Interval stepsize> numeric
Example: See Example "Using the DIMeasure function" on page 189.
Options: Option: R&S LCX-K106
Manual operation: See "Step Size" on page 101
DIMeasure:INTerval:TYPE <Interval parameter>
DIMeasure:INTerval:TYPE? <Interval parameter>
Selects the mode to determine the measurement steps within the sweep range
(DIMeasure:SWEep:MINimum to DIMeasure:SWEep:MAXimum).
Parameters for setting and query:
<Interval parameter> STEPsize | POINts
STEPsize
Measures in defined step sizes within the sweep range, set with
DIMeasure:INTerval:STEPsize.
POINts
Measures in increments calculated by the number of sweep
points (DIMeasure:INTerval:POINts on page 190) within
the sweep range.
Example: See Example "Using the DIMeasure function" on page 189.
Options: Option: R&S LCX-K106
Manual operation: See "Interval Type" on page 100
DIMeasure:SWEep:MAXimum <Sweep stop value>
Sets the stop value for the selected sweep parameter.
The value must be at least > DIMeasure:SWEep:MINimum. The maximum value
depends on the instrument model and installed options.
Parameters:
<Sweep stop value> numeric
Example: See Example "Using the DIMeasure function" on page 189.
Options: Option: R&S LCX-K106
Manual operation: See "Maximum" on page 100
DIMeasure:SWEep:MINimum <Sweep start value>
Sets the start value for the selected sweep parameter.
The value depends on the instrument model and installed options. The maximum value
must be at least < DIMeasure:SWEep:MAXimum.
