Remote control commands

R&S

NRPxxS(N)

108User Manual 1177.5079.02 ─ 15

Parameters:

<exclude_stop> Range: 0.0 to 1.0

*RST: 0.0

Default unit: Seconds

Manual operation: See "End Exclude" on page 47

See "End Exclude" on page 48

9.8.4 Configuring corrections

It is possible to set some parameters that compensate for a change of the measured

signal due to fixed external influences.

● Duty cycle corrections...........................................................................................108

● Offset corrections..................................................................................................109

● S-parameter correction......................................................................................... 109

● S-gamma corrections............................................................................................ 111

● I-gamma queries................................................................................................... 112

● Using the S-Parameters program..........................................................................113

9.8.4.1 Duty cycle corrections

The duty cycle is the percentage of one period during which the signal is active, when

pulse-modulated signals are corrected. The duty cycle is only evaluated in the continu-

ous average mode.

Remote commands:

[SENSe<Sensor>:]CORRection:DCYCle.......................................................................... 108

[SENSe<Sensor>:]CORRection:DCYCle:STATe................................................................108

[SENSe<Sensor>:]CORRection:DCYCle <duty_cycle>

Available in continuous average mode.

Sets the duty cycle for measuring pulse-modulated signals. The duty cycle defines the

percentage of one period during which the signal is active. If the duty cycle is enabled,

the R&S NRPxxS(N) considers this percentage when calculating the signal pulse

power from the average power.

Parameters:

<duty_cycle> Range: 0.001 to 100.00

*RST: 1.00

Default unit: Percent

Manual operation: See "Duty Cycle" on page 46

[SENSe<Sensor>:]CORRection:DCYCle:STATe <state>

Enables or disables the duty cycle correction for the measured value.

Configuring basic measurement parameters
