Remote control commands
R&S
®
NRPxxS(N)
84User Manual 1177.5079.02 ─ 15
TRIGger:ATRigger[:STATe] <state>
Effective only in trace mode and, irrespective of the set averaging factor, only one trace
is recorded.
Controls the automatic trigger function. If enabled, an artificial trigger is generated if the
delay time has elapsed after the measurement start and no trigger event has occurred.
The delay time is set using TRIGger:ATRigger:DELay.
Parameters:
<state> *RST: OFF
TRIGger:COUNt
<count>
Sets the number of measurement cycles to be performed when the measurement is
started using INITiate[:IMMediate].
This number equals the number of results that can be obtained from the sensor after a
single measurement. As long as the defined number of measurements is not executed,
the sensor automatically initiates another measurement internally when the current
result is available.
This command is particularly useful in conjunction with buffered measurements. For
example, to fill a buffer with a predefined size with measurements that have been trig-
gered externally or by *TRG without having to start the measurement multiple times.
Parameters:
<count> Range: 1 to 8192
*RST: 1
Example: See Chapter 10.3, "Performing a buffered continuous average
measurement", on page 146.
TRIGger:DELay <delay>
Sets the delay between the trigger event and the beginning of the actual measurement
(integration).
Parameters:
<delay> Range: -5.0 to 10.0
*RST: 0.0
Default unit: s
Manual operation: See "Trigger Delay" on page 53
TRIGger:DELay:AUTO <state>
If TRIGger:DELay:AUTO ON is set, no measurement is started until the power sensor
has settled. For this purpose, the delay value is automatically determined.
If a longer period is set using TRIGger:DELay, the automatically determined delay is
ignored.
Controlling the measurement
