Browser-based user interface
R&S
®
NRPxxS(N)
51User Manual 1177.5079.02 ─ 15
Turn off all test signals before zeroing. An active test signal during zeroing causes an
error.
Remote command:
CALibration<Channel>:ZERO:AUTO
Sensor Information
Displays information on the power sensor.
●
General information: manufacturer, sensor type, stock number, serial number, firm-
ware version
●
Network settings: MAC address, hostname, IP address, sensor name. A part of
them, you can configure under Chapter 6.5.4, "System settings", on page 53.
●
Important specifications: technology, frequency range, power limits, resolution, ...
●
Calibration information
Remote command:
SYSTem:INFO?
6.5.2 Averaging settings
Describes the parameters for automatic averaging.
Further information:
●
Chapter 9.8.1, "Configuring auto averaging", on page 102
Access: main dialog of the web user interface > navigation pane > "Averaging"
Filter Terminal Control...................................................................................................51
Auto Measurement Time............................................................................................... 52
Filter Terminal Control
Defines how the measurement results are output, also called termination control. See
also Chapter 9.5, "Controlling the measurement", on page 73.
"Moving"
Outputs intermediate values to facilitate early detection of changes in
the measured quantity. In the settled state, that means when the
number of measurements specified by the averaging factor has been
performed, a moving average is output.
"Repeating"
Specifies that a measurement result is not output until the entire mea-
surement has been completed. This means that the number of mea-
surement cycle repetitions is equal to the set averaging factor. If the
averaging factor is large, the measurement time can be very long.
Remote command:
[SENSe<Sensor>:]AVERage:TCONtrol
