Browser-based user interface
R&S
®
NRPxxS(N)
43User Manual 1177.5079.02 ─ 15
Result pane
Displays the measurement result for the selected measurement mode. It can display
only a value or a graph, depending on the selected measurement mode.
6.2 Setting the unit
You can set the unit for the different parameters by typing the corresponding letter after
the entered value.
1
2
3
Figure 6-2: Parameter
1 = Parameter name
2 = Value
3 = Unit
The following abbreviations are available:
Unit Keyboard key
Decibel d
Hertz h
Second s
Volt v
Watts w
Unit multiples Keyboard key
Giga g
Mega m
Kilo k
milli m
micro u
nano n
Example:
To set the unit to 1 GHz, enter 1g.
For certain units, you can select a different representation, depending on the require-
ments. For example, for the representation of the "Trigger Level", you can choose
Setting the unit
