Remote control commands

R&S

NRPxxS(N)

88User Manual 1177.5079.02 ─ 15

Determines which edge of the envelope power, with internal triggering, or increasing

voltage, with external triggering, is used for triggering.

Parameters:

<slope> POSitive | NEGative

POSitive

Rising edge

NEGative

Falling edge

*RST: POSitive

Manual operation: See "<Slope>" on page 52

TRIGger:SOURce

Selects the source for the trigger event detector.

Parameters:

EXTernal1 | EXT2 | EXTernal2

See Chapter 9.5.2.3, "Trigger sources", on page 76.

*RST: IMMediate

Manual operation: See "<Source>" on page 52

TRIGger:SYNC:PORT <sync_port>

Selects the external connection for the sync output of the power sensor. For more

information, see TRIGger:SYNC:STATe.

Parameters:

<sync_port> EXT1 | EXTernal1 | EXT2 | EXTernal2

*RST: EXT1

TRIGger:SYNC:STATe <state>

Usually used in combination with TRIGger:SENDer:STATe ON.

If enabled, blocks the external trigger bus as long as the sensor remains in the mea-

surement state. Thus, ensures that a new measurement is only started after all power

sensors have completed their measurements.

Make sure that the number of repetitions is the same for all power sensors involved in

the measurement. Otherwise, the trigger bus is blocked by any power sensor that has

completed its measurements before the others and has returned to the idle state.

Parameters:

<state> *RST: OFF

Controlling the measurement
