Remote control commands

R&S

NRPxxS(N)

98User Manual 1177.5079.02 ─ 15

[SENSe<Sensor>:][POWer:]TSLot[:AVG][:EXCLude]:MID[:STATe] <state>

Enables or disables the blanking out of time intervals in the timeslots.

Parameters:

<state> *RST: OFF

9.7.4 Trace measurement

The trace measurement determines the course of power over a defined time. During

the measurement time set by [SENSe<Sensor>:]TRACe:TIME, a large number of

measurements are performed. The result is returned as an array of values with a size

predefined by [SENSe<Sensor>:]TRACe:POINts. The length of an individual mea-

surement(-point) is determined from the ratio of measurement time and measurement

points. The entire result is called a "trace". Each trace must be triggered separately.

Remote commands:

[SENSe<Sensor>:]TRACe:AVERage:COUNt......................................................................98

[SENSe<Sensor>:]TRACe:AVERage:TCONtrol...................................................................98

[SENSe<Sensor>:]TRACe:AVERage[:STATe]..................................................................... 99

[SENSe<Sensor>:]TRACe:DATA?..................................................................................... 99

[SENSe<Sensor>:]TRACe:MPWidth?.............................................................................. 101

[SENSe<Sensor>:]TRACe:OFFSet:TIME......................................................................... 101

[SENSe<Sensor>:]TRACe:POINts...................................................................................101

[SENSe<Sensor>:]TRACe:REALtime...............................................................................102

[SENSe<Sensor>:]TRACe:TIME......................................................................................102

[SENSe<Sensor>:]TRACe:AVERage:COUNt <count>

Sets the number of readings that are averaged for one measured value. The higher the

count, the lower the noise, and the longer it takes to obtain a measured value.

Averaging is only effective, if [SENSe<Sensor>:]TRACe:AVERage[:STATe] ON is

set.

Parameters:

<count> Range: 1 to 65536

*RST: 4

[SENSe<Sensor>:]TRACe:AVERage:TCONtrol <mode>

Available in trace mode.

Defines how the measurement results are output. This is called termination control.

See also Chapter 9.5, "Controlling the measurement", on page 73.

Parameters:

<mode> MOVing | REPeat
