Remote control commands
R&S
®
NRPxxS(N)
85User Manual 1177.5079.02 ─ 15
Parameters:
<state> *RST: OFF
TRIGger:DTIMe <dropout_time>
Sets the dropout time for the internal trigger source. During this time, the signal power
must exceed (negative trigger slope) or undercut (positive trigger slope) the level
defined by the trigger level and trigger hysteresis. At least, this time must elapse before
triggering can occur again.
See Chapter 9.5.2.4, "Dropout time", on page 76.
Parameters:
<dropout_time> Range: 0.00 to 10.00
*RST: 0.00
Default unit: s
Manual operation: See "Dropout" on page 53
TRIGger:EXTernal<2...2>:IMPedance
<impedance>
Effective only if TRIGger:SOURce EXTernal2 is set.
Sets termination resistance of the second external trigger input. Choose the setting
that fits the impedance of the trigger source to minimize reflections on the trigger sig-
nals.
Suffix:
<2...2>
.
2
Parameters:
<impedance> HIGH | LOW
HIGH
~10 kΩ
LOW
50 Ω
*RST: HIGH
TRIGger:HOLDoff <holdoff>
Sets the hold-off time, see Chapter 9.5.2.5, "Hold-off time", on page 77.
Parameters:
<holdoff> Range: 0.00 to 10.00
*RST: 0.00
Default unit: Seconds
Manual operation: See "Holdoff" on page 53
