Operating concepts
R&S
®
NRPxxS(N)
39User Manual 1177.5079.02 ─ 15
Starting a measurement
For a detailed description, refer to the operating manual of the R&S Power Viewer. The
manual is installed automatically during the installation of the R&S Power Viewer.
1. Start the R&S Power Viewer.
2. Execute zeroing.
Note: Turn off all measurement power signals before zeroing. An active measure-
ment signal during zeroing causes an error.
3. Switch on the test signal of the signal source.
4. Select a measurement.
5. Start the measurement.
5.6 R&S Power Viewer Mobile
The R&S Power Viewer Mobile extends the functionality of the R&S Power Viewer to
Android-based devices, such as a smartphone and tablets.
For connecting the power sensor to USB-C type mobile phones (Android), use an
R&S NRP-ZKC cable. It enables the R&S Power Viewer Mobile to take power mea-
surements via the USB-C connection.
You can download the R&S Power Viewer Mobile free of charge from the Google Play
Store.
The 1MA215 "Using R&S
®
NRP Series Power Sensors with Android
TM
Handheld Devi-
ces" application note gives a detailed description on installation and features of the
R&S Power Viewer Mobile. The application note is provided on the documentation CD-
ROM and at:
www.rohde-schwarz.com/application/nrpz
5.7 R&S NRX
In a measurement, the R&S NRX uses all sensor-dependent measurement functions
and displays the results. Thus, you can configure both the measurement and the
power sensor.
Required equipment
●
R&S NRPxxS(N) power sensor
●
R&S NRP‑ZK8 cable to connect the sensor to the R&S NRX
●
R&S NRX
R&S
NRX
