Remote control commands

R&S

NRPxxS(N)

70User Manual 1177.5079.02 ─ 15

Usage: Event

9.4 Preparing for the measurement

Before starting a measurement, you need to do the following:

● Selecting the reference source............................................................................... 70

● Selecting a measurement path............................................................................... 70

● Selecting a measurement mode............................................................................. 71

● Configuring the measured values........................................................................... 72

9.4.1 Selecting the reference source

The ROSCillator subsystem contains commands for configuring the reference

source.

[SENSe<Sensor>:]ROSCillator:SOURce <source>

Sets the source of the reference oscillator. Refers typically to a precision, stabilized

time base.

Parameters:

<source> INTernal | EXTernal | HOST

INTernal

Internal precision oscillator

EXTernal | HOST

External signal supplied at the host interface connector.

*RST: If the sensor boots or reboots, the source is set to

INTernal. If the sensor is reset, the source setting is

kept unchanged.

Example:

ROSC:SOUR INT

9.4.2 Selecting a measurement path

The RANGe subsystem contains commands for selection of a measurement path.

Remote commands:

[SENSe<Sensor>:]RANGe................................................................................................70

[SENSe<Sensor>:]RANGe:AUTO......................................................................................71

[SENSe<Sensor>:]RANGe:CLEVel....................................................................................71

[SENSe<Sensor>:]RANGe <range>

Sets the selected path as active measurement path.

Parameters:

<range> The sensitivity of the paths differs.

Preparing for the measurement
