Remote control commands
R&S
®
NRPxxS(N)
112User Manual 1177.5079.02 ─ 15
[SENSe<Sensor>:]SGAMma:CORRection:STATe <state>
Enables or disables the use of the complex reflection coefficient to correct the interac-
tions of power sensor and signal source.
Parameters:
<state> *RST: OFF
Manual operation: See "<State>" on page 50
[SENSe<Sensor>:]SGAMma:MAGNitude <magnitude>
Sets the magnitude of the complex reflection coefficient of the source, Γ
source
.
Parameters:
<magnitude> 0.0 ≙ ideal matched source
1.0 ≙ total reflection
Range: 0.0 to 1.0
*RST: 0.0
Manual operation: See "Magnitude" on page 50
[SENSe<Sensor>:]SGAMma:PHASe <phase>
Sets the phase angle of the complex reflection coefficient of the source, Γ
source
.
Parameters:
<phase> Range: -360.0 to 360.0
*RST: 0.0
Manual operation: See "Phase" on page 50
9.8.4.5 I-gamma queries
For the current frequency, queries the complex input reflection coefficient Γ
in
of the fol-
lowing:
●
Power sensor if the S-parameter correction is disabled.
([SENSe<Sensor>:]SGAMma:CORRection:STATe OFF)
●
S-parameter device if the S-parameter correction is enabled, S11 in Figure 9-8.
([SENSe<Sensor>:]SGAMma:CORRection:STATe ON)
[SENSe<Sensor>:]IGAMma:MAGNitude?.........................................................................112
[SENSe<Sensor>:]IGAMma:PHASe?...............................................................................113
[SENSe<Sensor>:]IGAMma:EUNCertainty?......................................................................113
[SENSe<Sensor>:]IGAMma:MAGNitude?
Queries the magnitude of the complex input reflection coefficient Γ
in
.
