Remote control commands
R&S
®
NRPxxS(N)
97User Manual 1177.5079.02 ─ 15
[SENSe<Sensor>:][POWer:]TSLot[:AVG]:COUNt................................................................ 97
[SENSe<Sensor>:][POWer:]TSLot[:AVG]:WIDTh.................................................................97
[SENSe<Sensor>:][POWer:]TSLot[:AVG][:EXCLude]:MID:OFFSet[:TIME]..............................97
[SENSe<Sensor>:][POWer:]TSLot[:AVG][:EXCLude]:MID:TIME............................................97
[SENSe<Sensor>:][POWer:]TSLot[:AVG][:EXCLude]:MID[:STATe]........................................ 98
[SENSe<Sensor>:][POWer:]TSLot[:AVG]:COUNt <count>
Sets the number of simultaneously measured timeslots in timeslot mode. See Fig-
ure 9-3.
Parameters:
<count> Range: 1 to 128
*RST: 8
Manual operation: See "Number of Timeslots" on page 48
[SENSe<Sensor>:][POWer:]TSLot[:AVG]:WIDTh
<width>
Sets the length of the timeslot. See Figure 9-3.
Parameters:
<width> Range: 10.0e-6 to 0.10
*RST: 1.000e-3
Default unit: Seconds
Manual operation: See "Nominal Width" on page 48
[SENSe<Sensor>:][POWer:]TSLot[:AVG][:EXCLude]:MID:OFFSet[:TIME] <time>
Determines the distance from the start of the timeslots to the start of the interval to be
blanked out. See Figure 9-3.
Parameters:
<time> Range: 0.00 to 0.10
*RST: 0.00
Default unit: Seconds
[SENSe<Sensor>:][POWer:]TSLot[:AVG][:EXCLude]:MID:TIME <time>
Sets the length of the time interval in the timeslots to be excluded from the measure-
ment. See Figure 9-3. The parameter applies to each individual timeslot.
Note: Even if the exclusion interval exceeds the timeslot because, for example, its right
limit is outside the timeslot, correct results are obtained. In the extreme case, where
the interval length has been set to a value greater than the timeslot length, 0 W is out-
put as the measured power. No error message is output.
Parameters:
<time> Range: 0.00 to 0.10
*RST: 0.00
Default unit: Seconds
Configuring the measurement modes
