R&S NRP Series User Manual

Remote control basics
R&S
®
NRPxxS(N)
152User Manual 1177.5079.02 ─ 15
Besides USBTMC, the NRP legacy protocol is available to ensure the compatibility of
the R&S NRPxxS(N) power sensors with the R&S NRP‑Z series of power sensors. The
usage of this protocol is not recommended for new applications.
The resource string represents an addressing scheme that is used to establish a com-
munication session with the sensor. It is based on the sensor address and some instru-
ment- and vendor-specific information.
USB Resource String
The syntax of the used USB resource string is:
USB::<vendor ID>::<product ID>::<serial number>[::INSTR]
where:
●
<vendor ID> is the vendor ID for Rohde & Schwarz (0x0AAD)
●
<product ID> is the product ID for the Rohde & Schwarz sensor
●
<serial number> is the individual serial number on the rear of the sensor
Table 11-2: R&S NRPxxS(N) USB product IDs
R&S NRPxxS(N) power sensor USB product ID
R&S NRP8S 0x00E2
R&S NRP8SN 0x0137
R&S NRP18S 0x0138
R&S NRP18SN 0x0139
R&S NRP33S 0x0145
R&S NRP33SN 0x0146
R&S NRP33SN-V 0x0168
R&S NRP40S 0x015F
R&S NRP40SN 0x0160
R&S NRP50S 0x0161
R&S NRP50SN 0x0162
R&S NRP67S 0x024A
R&S NRP67SN 0x024B
R&S NRP67SN-V 0x026A
Example:
USB::0x0AAD::0x00E2::100001
0x0AAD is the vendor ID for Rohde & Schwarz.
0x00E2 is the product ID for the R&S NRP8S power sensor.
100001 is the serial number of the particular power sensor.
Remote control interfaces and protocols

R&S NRP Series Specifications

General

Product Type	Power Sensor
Connector Type	SMA, 3.5 mm, 2.4 mm
Interface	USB, LAN
Storage Temperature	-40°C to +70 °C
Dimensions	Dependent on model
Weight	Dependent on model
Compatibility	R&S Instruments
Type	Diode
