R&S NRP Series User Manual

Power sensor tour
R&S
®
NRPxxS(N)
30User Manual 1177.5079.02 ─ 15
Power over Ethernet status LED
The power status LED shows whether the sensor is correctly powered over PoE or not.
Color State
Green The sensor is powered over PoE. You can operate it using the Ethernet interface.
No light No PoE power is present.
Network status LED
The network status LED shows whether the LAN connection to the network is estab-
lished properly or not.
Color State
Green The power sensor is correctly connected to the network.
It has been assigned a valid IP address, either manually or via DHCP.
Red The power sensor is not connected to the network correctly.
Either the connection is erroneous or the sensor has not been assigned a valid IP address
yet.
LAN PoE interface

R&S NRP Series Specifications

General

Product Type	Power Sensor
Connector Type	SMA, 3.5 mm, 2.4 mm
Interface	USB, LAN
Storage Temperature	-40°C to +70 °C
Dimensions	Dependent on model
Weight	Dependent on model
Compatibility	R&S Instruments
Type	Diode
