Acc. / Dec. time
terminal 2
Acc. / Dec. time
terminal 1
Selected Acc. / Dec. time
Inactive Inactive
Acceleration time 1 is selected (b1.20)
Deceleration time 1 is selected (b1.21)
Inactive Active
Acceleration time 2 is selected (E2.00)
Deceleration time 2 is selected (E2.01)
Active Inactive
Acceleration time 3 is selected (E2.02)
Deceleration time 3 is selected (E2.03)
Active Active
Acceleration time 4 is selected (E2.04)
Deceleration time 4 is selected (E2.05)
Tab. 8-3: Acc. / Dec. time options
● 7: 3-wire running control
Used to control the frequency converter in 3-wire control mode. See parame-
ter E0.00.
● 8: Freewheeling to stop enabled
"Freewheeling to stop enabled" generates a STOP command and forces the
frequency converter to freewheel to stop regardless of the stopping mode
configured by b1.40.
● 9: Frequency increment UP command
● 10: Frequency decrement DOWN command
● 11: Zeroing of external terminal frequency setting
The above three functions are used to change the frequency set by terminals
UP / DOWN or clear the frequency to 0 Hz by the zeroing terminal. See pa-
rameters S3.32 and S3.33.
● 12: Reserved
● 13: Stopping DC braking enabled
This function is used when stopping mode is set with [b1.40]=0. For details,
see parameters b1.40 ~ b1.43.
● 14: Reserved
● 15: Simple PLC prohibited
If the PLC is running and this terminal is switched on, the frequency convert-
er will stop output and motor freewheels to stop. If this terminal is switched
off at this time, the frequency converter will stay standstill until the next RUN
command is activated.
[E2.30]
Xi = 15 Simple PLC status
≠0 OFF Running
≠0 ON Inactive
