<Stop> key is only valid when ‘frequency converter control commands’
b1.02 is set to ‘0: Set control commands by operating panel’.
● 1: Valid for all control means
<Stop> key is valid for all settings of ‘frequency converter control com‐
mands’ b1.02.
● <Stop> key as fault reset key is valid for all settings of ‘fre‐
quency converter control commands’ b1.02.
● If the frequency converter is controlled by external com‐
mands and stopped with the <Stop> key, the external com‐
mands have to be disabled and then re-enabled before re‐
starting the frequency converter.
S3.16
Fan control Factory default 0
Setting range 0, 1 Minimum unit 1
● 0: Temperature controlled
Automatically controls the start and stop of the cooling fan according to
the detected temperature of the heat sink.
● 1: Always on
The fan is always active when the frequency converter is running.
DOK-RCON02-FV*********-IB08-EN-P Bosch Rexroth AG 127/259
Rexroth Frequency Converter Fv
Parameter Settings
