Brake resistor
typecode
Impe‐
dance
[Ω]
Power
[W]
Fig.
Dimensions [mm]
Wiring
[mm
2
]
Terminal
[mm]
Cable
length
[mm]
Net
weight
[kg]
Type
H h B b T
0520-N100R-D 100 520
A
335 317 60 – 30 2.5 – 500 1.03 Alumi.
0390-N150R-D 150 390 265 247 60 – 30 2.5 – 500 0.80 Alumi.
0520-N230R-D 230 520 335 317 60 – 30 2.5 – 500 1.03 Alumi.
0260-N250R-D 250 260 215 197 60 – 30 2.5 – 500 0.62 Alumi.
0520-N350R-D 350 520 335 317 60 – 30 2.5 – 500 1.03 Alumi.
0260-N400R-D 400 260 215 197 60 – 30 2.5 – 500 0.62 Alumi.
0500-N550R-D 550 500 335 317 60 – 30 2.5 – 500 1.03 Alumi.
0150-N700R-D 700 150 215 197 40 – 20 2.5 – 500 0.32 Alumi.
0080-N750R-D 750 80 140 123 40 – 20 2.5 – 500 0.20 Alumi.
1K56-N040R-D 40 1560
B
485 470 50 30 107 2.5 M6 – 4.35 Alumi.
02K0-N047R-D 47 2000 550 534 50 30 107 4.0 M6 – 4.90 Alumi.
1K04-N050R-D 50 1040 400 384 50 30 107 2.5 M6 – 4.35 Alumi.
01K5-N068R-D 68 1500 485 470 50 30 107 2.5 M6 – 3.60 Alumi.
1K56-N070R-D 70 1560 485 470 50 30 107 2.5 M6 – 2.20 Alumi.
0780-N075R-D 75 780 400 382 61 40.5 59 2.5 M6 – 4.35 Alumi.
1K04-N090R-D 90 1040 400 384 50 30 107 2.5 M6 – 3.60 Alumi.
02K0-N110R-D 110 2000 550 534 50 30 107 4.0 M6 – 2.20 Alumi.
0780-N140R-D 140 780 400 382 61 40.5 59 2.5 M6 – 4.35 Alumi.
01K5-N150R-D 150 1500 485 470 50 30 107 2.5 M6 – 4.90 Alumi.
01K2-N180R-D 180 1200 450 434 50 30 107 2.5 M6 – 4.00 Alumi.
0800-N275R-D 275 800 400 382 61 40.5 59 2.5 M6 – 2.20 Alumi.
Tab. 10-12: Aluminum brake resistor dimensions
Alumi.: Brake resistor in aluminum housing.
