Brake resistor
typecode
Impedance
[Ω]
Power
[kW]
Dimensions
Wiring
[mm
2
]
Terminal
[mm]
Weight
[kg]
Type
B H t T h b
09K6-N13R6-A 13.6 9.6 410 685 145 170 642 340 6.0 M6 18.5 box
09K6-N016R-A 16 9.6 410 685 145 170 642 340 6.0 M6 18.5 box
12K5-N017R-A 17 12.5 410 685 145 170 642 340 6.0 M6 20.5 box
12K5-N018R-A 18 12.5 410 685 145 170 642 340 6.0 M6 20.5 box
12K5-N020R-A 20 12.5 410 685 145 170 642 340 6.0 M6 20.5 box
06K0-N020R-A 20 6.0 340 600 145 170 580 291 4.0 M6 14.0 box
10K0-N022R-A 22 10.0 410 685 145 170 642 340 6.0 M6 18.5 box
12K5-N022R-A 22 12.5 410 685 145 170 642 340 6.0 M6 20.5 box
10K0-N024R-A 24 10.0 410 685 145 170 642 340 6.0 M6 18.5 box
08K0-N027R-A 27 8.0 410 685 145 170 642 340 6.0 M6 16.5 box
10K0-N27R2-A 27.2 10.0 410 685 145 170 642 340 6.0 M6 18.5 box
04K8-N27R2-A 27.2 4.8 340 600 145 170 580 291 4.0 M6 12.0 box
10K0-N028R-A 28 10.0 410 685 145 170 642 340 6.0 M6 18.5 box
10K0-N032R-A 32 10.0 410 685 145 170 642 340 6.0 M6 18.5 box
04K8-N032R-A 32 4.8 340 600 145 170 580 291 4.0 M6 12.0 box
06K0-N040R-A 40 6.0 340 600 145 170 580 291 4.0 M6 14.0 box
04K5-N055R-A 55 4.5 340 600 145 170 580 291 4.0 M6 12.0 box
Tab. 10-13: Brake resistor box dimensions
box: Brake resistor box.
