REXROTH Fv Series User Manual

Logic control
Code Name Setting range Min. unit Default Attrib.
E2.21 Logic control mode
0: Inactive; 1: Mode 1
2: Mode 2; 3: Mode 3
1 0 ◆
E2.22 Logic control time factor 1...60 1 1 ◆
E2.23 Stage 1 action selection 0...31 1 0 ◆
E2.24 Stage 1 running time 0.0...5,000.0 s 0.1 0.0 ◆
E2.25 Stage 2 action selection 0...31 1 0 ◆
E2.26 Stage 2 running time 0.0...5,000.0 s 0.1 0.0 ◆
E2.27 Stage 3 action selection 0...31 1 0 ◆
E2.28 Stage 3 running time 0.0...5,000.0 s 0.1 0.0 ◆
E2.29 Stage 4 action selection 0...31 1 0 ◆
E2.30 Stage 4 running time 0.0...5,000.0 s 0.1 0.0 ◆
E2.31 Stage 5 action selection 0...31 1 0 ◆
E2.32 Stage 5 running time 0.0...5,000.0 s 0.1 0.0 ◆
E2.33 Stage 6 action selection 0...31 1 0 ◆
E2.34 Stage 6 running time 0.0...5,000.0 s 0.1 0.0 ◆
E2.35 Stage 7 action selection 0...31 1 0 ◆
E2.36 Stage 7 running time 0.0...5,000.0 s 0.1 0.0 ◆
E2.37 Stage 8 action selection 0...31 1 0 ◆
E2.38 Stage 8 running time 0.0...5,000.0 s 0.1 0.0 ◆
E2.39 Stage 9 action selection 0...31 1 0 ◆
E2.40 Stage 9 running time 0.0...5,000.0 s 0.1 0.0 ◆
E2.41 Stage 10 action selection 0...31 1 0 ◆
E2.42 Stage 10 running time 0.0...5,000.0 s 0.1 0.0 ◆
E2.43 Stage 11 action selection 0...31 1 0 ◆
E2.44 Stage 11 running time 0.0...5,000.0 s 0.1 0.0 ◆
E2.45 Stage 12 action selection 0...31 1 0 ◆
E2.46 Stage 12 running time 0.0...5,000.0 s 0.1 0.0 ◆
E2.47 Stage 13 action selection 0...31 1 0 ◆
E2.48 Stage 13 running time 0.0...5,000.0 s 0.1 0.0 ◆
E2.49 Stage 14 action selection 0...31 1 0 ◆
E2.50 Stage 14 running time 0.0...5,000.0 s 0.1 0.0 ◆
E2.51 Stage 15 action selection 0...31 1 0 ◆
E2.52 Stage 15 running time 0.0...5,000.0 s 0.1 0.0 ◆
DOK-RCON02-FV*********-IB08-EN-P Bosch Rexroth AG 95/259
Rexroth Frequency Converter Fv
Parameter Settings
