S3F84B8_UM_REV 1.00 1 OVERVIEW OF S3F84B8 MICROCONTROLLER

1-11

Figure 1-6 shows the Pin Circuit Type 1-2 (P2.3) in S3F84B8.

VDD

I/O

Digital Input

Pull-up

enable

Output Disable

(Input Mode)

Data

Analog Input

Enable

Analog Input

Pin Type 1

OPA output

OPA Enable Bit

Figure 1-6 Pin Circuit Type 1-2 (P2.3)
