SATO HR2 Series User Manual

Section 1: Introduction
Page 1-6 HR2 Series Operator Manual
1.3 PARTS IDENTIFICATION (cont’d)
1
2
3
4
6
5
Internal view when Ribbon unit is opened
Top cover
Ribbon pinch lever
Used to pinch the ribbon.
Ribbon unit
A unit for loading ribbon.
Ribbon unit lever
Press this lever to release ribbon unit from the
top cover.
Ribbon supply shaft bearing
To hold the Ribbon supply shaft.
Ribbon rewind shaft bearing
To hold the Ribbon rewind shaft.
2
3
4
5
6
1
