SATO HR2 Series User Manual

Section 1: Introduction
HR2 Series Operator Manual Page 1-7
1.3 PARTS IDENTIFICATION (cont’d)
Media and Rollers Section
6
7
8
1
2
3
4
5
Feed roller
Enable smooth feeding of the label.
Label guide lock lever
Used to lock the label guide.
Label guide
Used to guide the label.
Platen roller
Enable smooth movement of the label during
printing.
Dispenser roller
Enable smooth movement of the label during
dispensing.
Roll shaft bearing
Used to latch roll holder.
Roll media guide lock lever
Used to lock the roll media guide.
Roll media guide
Set to meet the size of the media used.
1
2
3
4
5
6
7
8
