Schweitzer Engineering Laboratories SEL-787 - Page 241

Date _______________
Group______________
Date Code 20081022 Instruction Manual SEL-787 Relay
SET.29
of 68
SEL-787 Settings Sheets
Global Settings (SET G Command)
Analog Inputs
For the following settings, x is the card position (3, 4, or 5 in Slot C, D, and E, respectively).
AIx01
AIx01 TAG NAME (8 characters 0–9, A–Z, _) AIx01NAM :=
AI
x01 TYPE (I, V) AIx01TYP :=
If AI
x01TYP = I
AI
x01 LOW IN VAL (–20.480 to +20.480; mA) AIx01L :=
AI
x01 HI IN VAL (–20.480 to +20.480; mA) AIx01H :=
If AI
x01TYP = V
AI
x01 LOW IN VAL (–10.240 to +10.240 V) AIx01L :=
AI
x01 HI IN VAL (–10.240 to +10.240 V) AIx01H :=
NOTE: Set Warn and Alarm to a value between Engr Low and
Engr High settings.
AI
x01 ENG UNITS (16 characters) AIx01EU :=
AI
x01 EU LOW (–99999.000 to +99999.000) AIx01EL :=
AI
x01 EU HI (–99999.000 to +99999.000) AIx01EH :=
AI
x01 LO WARN L1 (OFF, –99999.000 to +99999.000) AIx01LW1 :=
AI
x01 LO WARN L2 (OFF, –99999.000 to +99999.000) AIx01LW2 :=
AI
x01 LO ALARM (OFF, –99999.000 to +99999.000) AIx01LAL :=
AI
x01 HI WARN L1 (OFF, –99999.000 to +99999.000) AIx01HW1 :=
AI
x01 HI WARN L2 (OFF, –99999.000 to +99999.000) AIx01HW2 :=
AI
x01 HI ALARM (OFF, –99999.000 to +99999.000) AIx01HAL :=
AIx02
AIx02 TAG NAME (8 characters 0–9, A–Z, _) AIx02NAM :=
AI
x02 TYPE (I, V) AIx02TYP :=
If AI
x02TYP = I
AI
x02 LOW IN VAL (–20.480 to +20.480; mA) AIx02L :=
AI
x02 HI IN VAL (–20.480 to +20.480; mA) AIx02H :=
If AI
x02TYP = V
AI
x02 LOW IN VAL (–10.240 to +10.240 V) AIx02L :=
AI
x02 HI IN VAL (–10.240 to +10.240 V) AIx02H :=
AI
x02 ENG UNITS (16 characters) AIx02EU :=
AI
x02 EU LOW (–99999.000 to +99999.000) AIx02EL :=
AI
x02 EU HI (–99999.000 to +99999.000) AIx02EH :=
AI
x02 LO WARN L1 (OFF, –99999.000 to +99999.000) AIx02LW1 :=
AI
x02 LO WARN L2 (OFF, –99999.000 to +99999.000) AIx02LW2 :=
AI
x02 LO ALARM (OFF, –99999.000 to +99999.000) AIx02LAL :=
AI
x02 HI WARN L1 (OFF, –99999.000 to +99999.000) AIx02HW1 :=
